Automatic Programmable Melting Point Apparatus - Model : ThermoCal50

Name: Automatic Programmable Melting Point Apparatus - Model : ThermoCal50
Brand: ANALAB SCIENTIFIC INST. PVT. LTD.
Price: 228600 INR
Availability: InStock

228600 INR/Number

Get a Price/Quote

Product Details:

Measurement Range Up to 400C
Temperature Range Ambient +10C to 400C
Capacity 3 Capillaries per run
Frequency 50/60 Hz
Core Components Microprocessor controller, capillary holder, heating block
Automation Grade Fully Automatic
Model No ThermoCal50
Click to View more

Request to Call Back Send Inquiry

Product Details
Product Description

Automatic Programmable Melting Point Apparatus - Model : ThermoCal50 Price And Quantity

Price 228600 INR/Number
Minimum Order Quantity 1 Number

Printer Output Optional
Data Storage Yes, with internal memory
Heating Rate Selectable 0.5°C to 10°C/min
Start Delay Facility Programmable
Temperature Resolution 0.1°C
Interface USB port for data transfer
Sample Capacity Simultaneous measurement of 3 samples
Calibration Automatic and manual calibration
Safety Feature Over temperature protection, auto shut-off

Automatic Programmable Melting Point Apparatus - Model : ThermoCal50 Product Specifications

Display Type Large LCD digital display
Model No ThermoCal50
Feature Programmable temperature ramp, auto calculation, rapid cooling
Power Source 230V AC
Usage Determining melting point of substances in labs
Voltage 230V
Accuracy 0.5C
Weight Approx. 8 kg
Frequency 50/60 Hz
Core Components Microprocessor controller, capillary holder, heating block
Automation Grade Fully Automatic
Dimension (L*W*H) 340 x 250 x 210 mm
Measurement Range Up to 400C
Equipment Materials Powder coated metal housing, high-grade glass capillaries
Type Automatic Programmable Melting Point Apparatus
Temperature Range Ambient +10C to 400C
Capacity 3 Capillaries per run

Printer Output Optional
Data Storage Yes, with internal memory
Heating Rate Selectable 0.5°C to 10°C/min
Start Delay Facility Programmable
Temperature Resolution 0.1°C
Interface USB port for data transfer
Sample Capacity Simultaneous measurement of 3 samples
Calibration Automatic and manual calibration
Safety Feature Over temperature protection, auto shut-off

Product Description

Unlock peerless laboratory performance with the ThermoCal50 Automatic Programmable Melting Point Apparatus, now available at a valuable reduced price-an unmissable deal for researchers and quality analysts. Engineered for prime accuracy, it features 0.1C temperature resolution, selectable heating rates, and simultaneous analysis of up to three samples. Effortlessly store critical data thanks to built-in memory, while safety is maximized with over-temperature protection and auto shut-off. Promotion includes USB connectivity, optional printer output, and user-friendly digital display. Ideal for pharmaceutical, academic, and industrial labs across India.

Distinguished Features and Versatile Applications

The ThermoCal50 offers programmable temperature ramps, rapid cooling, and the capability to measure three samples simultaneously-making it ideal for high-throughput labs. Its automatic and manual calibration, paired with a large digital LCD, ensures reliable and precise measurements. Widely adopted in pharmaceutical, research, and educational facilities, this apparatus stands out for its robust construction, automated accuracy, and secure operation, making it suited for any commercial or academic environment demanding prime melting point analysis.

Sample Policy, Export Markets, and Domestic Distribution

Orders for the ThermoCal50 are processed promptly, with delivery estimates provided at the time of purchase. Our sample policy accommodates evaluation units for institutional buyers upon confirmed order processing. The model serves major export destinations across Asia, Europe, and Africa, while being readily available in key Indian metropolitan and industrial hubs. Reliable delivery and support ensure you receive the apparatus as scheduled, empowering laboratories globally to benefit from our streamlined supply chain.

FAQ's of Automatic Programmable Melting Point Apparatus - Model : ThermoCal50:

Q: How does the ThermoCal50 provide accurate melting point measurements?

A: The ThermoCal50 employs a microprocessor controller combined with high-grade sensors, automatic/manual calibration, and precise temperature resolution of 0.1C to ensure highly accurate melting point determinations.

Q: What are the benefits of the programmable features in this apparatus?

A: Programmable temperature ramps and start delay facilities enable flexible operation, allowing users to tailor the process to different sample requirements, increasing workflow efficiency and accuracy.

Q: When should the calibration process be performed?

A: Calibration should be conducted when setting up the device or as specified in your standard operating procedures. Both automatic and manual calibration options provide consistent reliability before conducting measurements.

Q: Where can data from the ThermoCal50 be exported or stored?

A: Data can be stored on the device's internal memory or transferred easily via the USB port to external devices. An optional printer output is also available for hard copy documentation.

Q: How is user safety ensured while operating the ThermoCal50?

A: Safety is maintained through over-temperature protection, an auto shut-off feature, and robust powder-coated metal housing, reducing risk during extended laboratory use.
