Tap Density Test Apparatus

59800.0 INR

Get a Price/Quote

Product Details:

Features Number of strokes selectable, dual cylinder operation, easy to operate, compact design
Shape Rectangular
Display Type LED digital display
Speed Range Tap frequency: 300 10 taps/min
Glass Type Borosilicate Glass
Control Type Digital (preset counter)
Power Supply 230V AC, 50Hz
Click to View more

Request to Call Back Send Inquiry

Product Details
Product Description

Tap Density Test Apparatus Price And Quantity

Price 59800.0 INR
Minimum Order Quantity 01 Number, Number, Number
Price Range 60000.00 - 70000.00 INR

Mounting Type Benchtop
Operating Environment Ambient
Stroke Height 14±2 mm
Finish Powder Coated
Weight Approx. 13 kg
No. of Cylinders 2 (dual cylinder model)
Conforms to Standards USP, ASTM & IP method compliant
Preset Counter Up to 9999 strokes
Safety Features Overload protection, safety cover on mechanism
Noise Level Low noise operation (<60 dB)
Operation Mode Automatic

Tap Density Test Apparatus Product Specifications

Voltage 230V AC, 50 Hz Volt (v)
Features Number of strokes selectable, dual cylinder operation, easy to operate, compact design
Type Other
Speed Range Tap frequency: 300 10 taps/min
Display Type LED digital display
Shape Rectangular
Power 13 W Watt (w)
Dimension (L*W*H) 290mm x 220mm x 350mm (approx) Millimeter (mm)
Control Type Digital (preset counter)
Glass Type Borosilicate Glass
Equipment Materials Mild Steel (MS) powder coated
Material Stainless Steel & Glass (Borosilicate)
Application Pharma laboratories for measuring tap density
Equipment Type Laboratory Instrument
Power Supply 230V AC, 50Hz
Capacity (Ltr) Standard Cylinder: 100 ml Milliliter (mL)
Accuracy 1 tap mg

Mounting Type Benchtop
Operating Environment Ambient
Stroke Height 14±2 mm
Finish Powder Coated
Weight Approx. 13 kg
No. of Cylinders 2 (dual cylinder model)
Conforms to Standards USP, ASTM & IP method compliant
Preset Counter Up to 9999 strokes
Safety Features Overload protection, safety cover on mechanism
Noise Level Low noise operation (<60 dB)
Operation Mode Automatic

Tap Density Test Apparatus Trade Information

Delivery Time 1 Week

Product Description

Model : TDCal10 | Make : ANALAB | HSN Code : 90318000

Technical Specification

No. of Station : Two
USP Compliance :
1) USP1 (300 taps per min.)
2) USP2 (250 taps per min.)
3) USP3 (55 taps per min.) Not Available with this Model
Stroke Height : 14mm 2mm / 3mm 0.2mm
Stroke / Minute : 300 10, 250 10, 55 5
No. of taps : 1-9999
Rotating and tapping motion : Simultaneous
Display of Strokes/min : Simultaneously - Set & Actual
Cylinder Supports : 100ml and 250 ml
Pharmacopeia Complies : As per USP, IP, Ph. Eur.
Calculation of result : Bulk Density, Tapped density, Compressibility index and Hauser ratio.
Display : 16 x 2 Line Alphanumeric Backlit LCD
Keypad : Membrane waterproof polycarbonate soft touch keypad compliance to UL/ROHS
Analysis Data Storage : More than 500 analysis data which can be viewed & Print, company name, analysis date & time, record number, *Username, *Sample Name, *Bath Number/ID, Tap/minute, Tap Hight, Tap Count 1, Tap Count 2, Tap Count 3, Tap Count Final, Tap Density, Bulk Density, Compressibility Index, & Hausner Ratio, instrument serial number, Instrument Make & Model & *Signature etc. Secondly, analysis data can be print online without saving analysis data in Instrument.
(*: Not possible to enter data by instrument keypad but it will be handwritten)
Searching of data : With record number by scrolling.
Report Formation : As per Non-GLP Compliance
Printer Interface : Centronics Parallel Port / Serial (RS-232 C) Port
Printer : 40 / 80 Column Dot Matrix Printer (Printer must procure optionally)
Power Supply : 230VAC 10%, 50 Hz
Dimensions:
Net Dimension: 38 x 31 x 24 cm (L x W x H)
Gross Dimension: 50 x 44 x 51 cm (L x W x H)
Weight:
Net Weight: 8.5 kg
Gross Weight: 15 kg

FAQs of Tap Density Test Apparatus:

Q: How does the dual cylinder model benefit laboratory testing?

A: The dual cylinder setup allows simultaneous analysis of two powder samples, improving efficiency and comparability within laboratory workflows, making routine testing remarkably faster and more consistent.

Q: What standards does the Tap Density Test Apparatus comply with?

A: This apparatus conforms to USP, ASTM, and IP standards, ensuring reliable and reproducible measurements compliant with international pharmaceutical and industrial regulations.

Q: Where can the Tap Density Test Apparatus be installed?

A: The instrument is designed for benchtop mounting, optimizing space in laboratory environments wherever precise tap density measurements are required.

Q: What are the primary safety features of the machine?

A: Key safety features include integrated overload protection to prevent mechanical strain and a robust safety cover over the mechanism, protecting operators during testing.

Q: What is the process for setting the desired number of strokes?

A: Users simply program the required stroke countup to 9999using the digital preset counter, and the automatic mode ensures the device performs the sequence without manual intervention.

Q: When is it advisable to use the digital tap density apparatus?

A: It is ideal for routine quality control, research and development, or any situation where accurate tap density determination of powders is critical in pharmaceutical or related industries.

Tell us about your requirement

Price:

Quantity

Select Unit

50
100
200
250
500
1000+

Additional detail

Mobile number

Other Products in 'Ultrasonic Bath / Sonicator' category

Ultrasonic Bath Device ( Sonicator ) Price : 18800.0 INR/Number Minimum Order Quantity : 1 Display Type : LED Display Shape : Rectangular Power : 250 Watts Watt (w) Voltage : 220 V AC Volt (v) Features : Adjustable Timer, Temperature control, Overload protection, Easy to use, Chemical resistant, Compact Design Type : Other Application : Laboratory sample cleaning, sonication, homogenization, degassing Equipment Type : Laboratory Sonicator Capacity (Ltr) : 6 Liters Liter (L) Power Supply : Electric Accuracy : 2 C C Heating Capacity : Adjustable up to 80 C Ampere Dimension (L*W*H) : 350 mm x 300 mm x 260 mm Millimeter (mm) Temperature Resistance : Up to 80 C Control Type : Digital & Manual Equipment Materials : Stainless Steel, ABS Plastic Glass Type : Borosilicate Material : Stainless Steel Speed Range : Variable Ultrasonic Frequency

Send Inquiry

Supplied Without Desiccator Price : 52800.0 INR Display Type : Analog Shape : Rectangular Power : 1000 W Watt (w) Voltage : 220 V Volt (v) Features : Uniform heating, energy efficient, high durability Type : Other Application : Drying and sterilization in laboratories Equipment Type : Oven Capacity (Ltr) : 45 L Liter (L) Power Supply : AC Mains Accuracy : 1 C C Heating Capacity : 1000 W Watt (W) Dimension (L*W*H) : 350 x 350 x 350 mm Millimeter (mm) Temperature Resistance : Up to 250 C Control Type : Thermostatic Equipment Materials : Powder coated mild steel Glass Type : Tempered glass window Material : Mild Steel Body
